| Freins | Shimano BR-MT420, hydraulische Scheibenbremse |
| Leviers de frein | Shimano BL-M4100 |
| Cadre | Alloy Al-6061 T6 Custom MONO tubing, Smooth Welding, Cross Fun Geometry |
| Transmission | Shimano Deore RD-M4120 Shadow Plus |
| Manettes de vitesses | Shimano Deore SL-M4100-IR, 10-speed |
| Nombre de vitesses | 10 |
| Fourche | SR Suntour NVX30 NLO |
| Débattement fourche (mm) | 80 |
| Pédalier | Shimano FC-EM600, 38 Zähne |
| Cassette | Shimano Deore CS-M4100-10, 11-46 Zähne |
| Chaîne | KMC X10e EPT |
| Jeu de direction | Acros AZX-251, Zero Stack, 1-1/8“ |
| Cintre | ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 720mm, 31.8mm |
| Poignées | Velo VLG-1879D2 |
| Potence | ONE1 Sport MAS-D61808 Alloy, 31.8xE65mm, ±15° |
| Selle | Selle Royal Ariel |
| Tige de selle | ONE1 Alloy, SP C207, 30.9x350mm |
| Jantes | WTB SX19, 32 Loch |
| Pneus | WTB Riddler Comp, 29x1.75" |
| Moyeu avant | Shimano TX HB-TX505, 32 Loch Center Lock, Schnellspanner |
| Moyeu arrière | Shimano TX FH-TX505-8, 32 Loch, Center Lock, M10x135mm, Schnellspanner |
| Rayons | Sapim Leader, Stainless Black |
| Fabricant / modèle de moteur | Shimano Steps EP8 |
| Écran | Shimano SC-E5003 |
| Batterie | Darfon, 36V, 504Wh, 250W, in Rahmen integriert |
| Capacité de la batterie (Wh) | 504 |
