Corratec is known for its idiosyncrasies. On the Corones aluminium frame, this can be seen in the "lowered" chainstays, which only point upwards just before the dropouts. During the ride, the sporty riding position is the first thing you notice, followed by the exorbitant riding stability. The equipment is at class level: complete Ultegra groupset, stiff, fairly heavy DT Swiss wheels, good Conti tyres. The saddle cover is so flexible that it hits the post head on hard impacts. A unique selling point of Corratec is the sizing system, which is based on length rather than height. However, with only five lengths and relatively large jumps, the choice is quite limited.
Price 1,699 Euro
Weight 8.8 kilos
Available in specialised shops
Reference/Info www.corratec.com
Weight frame/fork/steering bearing* 1.672/568/80 g
Frame sizes** 46, 48, 50, 55, 60 cm
Seat/steering angle 73°/74°
Seat/top tube/head tube 550/585/174 mm plus 20 mm headset cap
Wheelbase/caster 1,010/48 mm
Stack/Reach/STR*** 572/415 mm/1.38
EQUIPMENT
Fork Corratec
Steering bearing No name ( top 1-1/8, bottom 1-1/2 inch)
Brakes/gears/bottom bracket Shimano Ultegra (50/34 t., BS A)
Wheels/tyres DT Swiss R1900/Continental Grand Prix
Handlebar/stem Zzyzx/Zzyzx
Saddle/post Corratec/Zzyzx (27.2 mm)
*Weighed weights. **Manufacturer's specification, test size greased. ***Stack/reach: projected vertical/horizontal measurement from the centre of the bottom bracket to the top of the headset cap; STR (stack to reach): Values from 1.45 to 1.55 indicate a sporty riding position, values below that are race-like, above that comfortable.
