| Rear brakes | Hydraulic disc brake SRAM Red AXS
SRAM CenterLine X, Centre Lock disc mount, rounded edge, 160 mm
Max. Brake disc pressure |
| Front brakes | Hydraulic disc brake SRAM Red AXS
SRAM CenterLine X, Centre Lock disc mount, rounded edge, 160 mm
Max. Brake disc pressure |
| Frame | 800 Series OCLV Carbon, KVF tube profile (Kammtail Virtual Foil), IsoFlow seat tube, invisible cable routing, aerodynamic 3S chain guide, T47 bottom bracket, flat mount disc brake mount, 142 x 12 mm thru axle |
| Shift levers | SRAM RED eTap AXS, 12-speed // SRAM RED eTap AXS, 12-speed |
| Front derailleur | SRAM RED eTap AXS, braze-on version |
| Fork | Madone KVF full carbon, tapered carbon steerer, internal brake routing, flat mount disc, carbon dropouts, 12x100mm thru axle |
| Crankset | SRAM RED AXS with power meter, 48/35 t, DUB, 165 mm crank arm length
SRAM DUB, T47, with thread, internal bearings |
| Sprocket | SRAM XG-1290, 10-33 T, 12-speed |
| Drive | SRAM RED D1, 12-speed |
| Handlebar | Madone integrated handlebar/stem unit, OCLV carbon, 380 mm width, 80 mm stem length |
| Saddle | Aeolus P2 RSL, carbon struts, 155 mm width |
| Seatpost | Madone, aerodynamic internal carbon seat tower attachment, integrated rear light mount, 0 mm offset, short |
| Wheelset | Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm profile height, 100 x 12 mm thru axle
Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm profile height, SRAM XD-R freehub body, 142 x 12 mm thru axle |
