The carbon frame of the TCR Composite has been in the programme for a while, but because Giant is one of the pioneers of technical trends such as press-fit bottom brackets or tapered steerer tubes, it still looks fresh. Details such as the aerodynamic seatpost are usually only found on more expensive bikes. However, the expense of the frame obviously forces the manufacturer to economise on the equipment. The Ultegra drivetrain is combined with Shimano cranks and brakes without a groupset, while the wheels and tyres bear the manufacturer's own label. None of this is a problem, but the competition sometimes offers more. The bike scores points with pleasant damping, directional stability and a moderately sporty riding position.
Price 1,600 Euro
Weight 8.4 kilos
Available in specialised shops
Reference/Info www.giant-bicycles.de
Weight frame/fork/steering bearing* 1.180/516/72 g
Frame sizes** 46,5; 50; 53,555.5; 58.5 cm
Seat/steering angle 71 ,5°/73°
Seat/top tube/head tube 535/575/169 mm plus 15 mm headset cap
Wheelbase/caster 985/54 mm
Stack/Reach/STR*** 567/387 mm/1.46
EQUIPMENT
Fork Giant
Steering bearing Giant (top 1-1/8, bottom 1-1/4 inch)
Brakes Shimano R56 1
Circuit Shimano Ultegra
Bottom bracket Shimano R600 (50/34 t., Pr essfit)
Wheels/tyres Giant PR-2/Giant PR-3
Handlebar/stem Giant/Giant
Saddle/post Giant/ Giant (aero profile)
*Weighed weights. **Manufacturer's specification, test size greased. ***Stack/reach: projected vertical/horizontal measurement from the centre of the bottom bracket to the top of the headset cap; STR (stack to reach): Values from 1.45 to 1.55 indicate a sporty riding position, values below that are race-like, above that comfortable.
