The frame, which has been updated several times, has an independent and modern look. With press-fit bearings, tapered steerer tube and Di2 preparation, it is technically up to date. The test bike fell slightly short of expectations in terms of the measured values, as an identical model (in TOUR 4/2012 ->) 100 grams lighter and a good 10 per cent stiffer. The fork comfort could also be better. Cube traditionally has a good hand when it comes to equipment: The Ultegra groupset is joined by high-quality components from Syntace, whose HiFlex post helps the Litening on the saddle to achieve acceptable comfort. The most effective tuning measure is probably the wheels; the DT Swiss models fitted are comparatively heavy and were noticeable with slight brake stuttering on the front wheel when riding fast.
Price 2,699 Euro
Weight 7.7 kilos
Available in Specialised trade
Reference/Info www.cube.eu
Frame sizes** 50, 53, 56, 58, 60, 62, 64 cm
Seat/steering angle 74°/74°
Seat/top tube/head tube 540/560/163 mm plus 15 mm headset cap
Wheelbase/caster 990/49 mm
Stack/Reach/STR*** 564/398 mm/1.42
EQUIPMENT
Steering bearing FSA, top 1-1/8, bottom 1-1/2 inch
Brakes/gears/bottom bracket Shimano Ultegra (50/34 t., press-fit)
Wheels/tyres DT Swiss CSW RA 2.0/Schwalbe Ultremo ZX
Handlebar/stem Syntace Racelite 2014/F109
Saddle/post Selle Italia X1/Syntace P6 HiFlex (27.2 mm)
MEASURED VALUES & INDIVIDUAL NOTES
Weight of complete wheel (without pedals) 7.7 kg
Frame/fork/steering bearing weight 977/355/74 g
Standardised weight frame set**** 1.442 g: 2 , 0
Steering head stiffness 81 Nm/°: 2 , 7
Lateral stiffness fork 45 N/mm: 2 , 3
Bottom bracket stiffness 57 N/mm: 1 , 7
Comfort frame 155 N/mm: 1 , 0
Comfort fork 100 N/mm: 5 , 0
* The frame set accounts for 40 per cent of the overall score and the features for 60 per cent. These ratings include individual grades, which we have only printed in part for reasons of space. The grades are calculated up to the final grade with all decimal places; however, for the sake of clarity, all grades are given with rounded decimal places.
** Tested frame size greased.
*** Stack/reach: projected vertical/horizontal measurement from the centre of the bottom bracket to the top of the headset; STR (stack to reach): Values between 1.45 and 1.55 indicate a sporty seating position, values below that are race-like, above that comfortable.
**** Adjusted weight for frame size 57 cm and fork steerer length 225 mm.
