With a set weight of 1,183 grams, the frame is now one of the lightest on the market - with unchanged high riding stability. Even more impressive is how well the suspension filters vibrations. Special tube cross-sections, the addition of damping basalt fibres in the rear triangle and fork as well as the ingenious VCLS parallelogram seatpost (€ 130 surcharge) perform a highly effective joint task that sets the model apart from many others. Visually, the frame, which has a technically sober appearance typical of the brand, is state-of-the-art with integrated cables and a press-fit bottom bracket. The geometry concept is interesting: the ratio of frame height to length is almost the same across all sizes. The good equipment is another argument in favour of the bike, which could at best be criticised for the limited adjustment range on the handlebars.
Price 3,130 Euro
Weight 6.8 kilos
Available via the Mail order business
Reference/Info www.canyon.com
Frame sizes** XS, S, M, L, XL, XXL, XXXL
Seat/steering angle 74°/74,5°
Seat/top tube/head tube 565/570/168 mm plus 19 mm headset cap
Wheelbase/caster 995/48 mm
Stack/Reach/STR*** 580/402 mm/1.44
EQUIPMENT
Steering bearing Acros Ai70, top 1-1/4, bottom 1-1/2 inch
Brakes/gears/bottom bracket Shimano Ultegra (50/34 t., press-fit)
Wheels/tyres Mavic Ksyrium SLS/Mavic Yksion Pro
Handlebar/stem Ritchey WCS (aluminium)/Ritchey WCS
Saddle/post Selle Italia SLS/Canyon VCLS 2.0 (27.2 mm)
MEASURED VALUES & INDIVIDUAL NOTES
Weight of complete wheel (without pedals) 6.8 kg
Frame/fork/steering bearing weight 804/309/59 grammes
Standardised weight frame set**** 1.183 g: 1 , 0
Steering head stiffness 106 Nm/°: 1 , 0
Lateral stiffness fork 52 N/mm: 1 , 3
Bottom bracket stiffness 67 N/mm: 1 , 0
Comfort frame 119 N/mm: 1 , 0
Comfort fork 73 N/mm: 2 , 3
* The frame set accounts for 40 per cent of the overall score and the features for 60 per cent. These ratings include individual grades, which we have only printed in part for reasons of space. The grades are calculated up to the final grade with all decimal places; however, for the sake of clarity, all grades are given with rounded decimal places.
** Tested frame size greased.
*** Stack/reach: projected vertical/horizontal measurement from the centre of the bottom bracket to the top of the headset; STR (stack to reach): Values between 1.45 and 1.55 indicate a sporty seating position, values below that are race-like, above that comfortable.
**** Adjusted weight for frame size 57 cm and fork steerer length 225 mm.
