The very well-equipped bike is in the runner-up group in the wind tunnel - which is probably a pity considering the price, as the frame isn't even available elsewhere. At 40 km/h, 13 watts separate the bike from the Scott Plasma 3, but the Speedmax CF 9.0 Pro scores points with its decent stiffness values and professional image: the frame is also ridden by the riders of the Omega-Pharma-Lotto team. The unspectacular but very tidy exterior is appealing: the head tube is slim and tapered, the down tube in particular is extremely narrow in cross-section, all cables run inside the frame and the adjustment screws for the rear wheel are easy to operate. The design of the seatpost with its intelligent clamping mechanism is exemplary - why isn't it always this easy? The high frame set weight is of secondary importance for the intended use.
Price 1,899/4,999 Euro 1)
Weight 8.0 kilos
available by mail order
Reference/Info www.canyon.com
Weight Frame/fork/headset/seatpost* 1,662/504 /58/331 grams
Frame sizes** S, M, L
Seat angle 76°-79°
Steering angle 73° Seat/upper/ lower
Head tube 540/ 535/125 mm
Wheelbase/caster 990/61 mm
Stack/Reach/STR*** 520/436 mm/1.19
EQUIPMENT
Steering bearing Cane Creek, 1-1/8 inch
Brakes/brake lever SRAM Red/SRAM 900TT
Gear lever/gear shift SRAM R2C/ SRAM Red
Bottom bracket Vision Trimax (54/42 t., BSA)
Impellers Zipp 404/808
Tyres Conti Competition (tubular tyre)
Saddle Selle Italia SLR T1
Handlebar/stem Profile CX3
1) Frame set/complete bike. *Weighed weights. **Manufacturer's specification, test size greased. ***Stack/reach: projected vertical/horizontal measurement from the centre of the bottom bracket to the top of the head tube (centre); STR (stack to reach): Values below 1.30 indicate a race-like riding position, values of 1.20 and smaller indicate an extreme time trial position.
