GIANT Propel Advanced Red
Model: Propel Advanced Red
Model year: 2026
Category: Rennrad
Frame material: Carbon
Weight: 6.43 kg
Wheel size: 28"/622mm
Verdict on the Propel Advanced Red test
Over the years, the Giant Propel has mutated from a pure aero racer to a versatile race all-rounder. The new edition continues this claim: the bike hasn't got any faster - but it is incredibly light
Test result
| Property | Weighting | Grade |
|---|---|---|
| Lab | 85% | 1,5 |
| Complete bike weight | 25% | 1,3 |
| Air resistance | 25% | 1,7 |
| Rear comfort | 10% | 1,7 |
| Front comfort | 5% | 2,7 |
| Acceleration | 10% | 1,0 |
| Ride stability | 10% | 1,0 |
| Equipment | 15% | 1,2 |
| Brakes | 5% | 1,0 |
| Shifting | 5% | 1,0 |
| Tires | 5% | 1,5 |
| Final grade | 1,4 |
Strengths and weaknesses
| Complete bike weight | 6434 g |
| Aerodynamics | 209 Watt |
| Ride stability | 9,53 N/mm |
| Rear comfort | 109,00 N/mm |
| Front comfort | 96,51 N/mm |
| Sprint / BB stiffness | 76,22 N/mm |
Geometry - measurements overview
H
G
F
D
B
E
A
J
C
I
K
L
ML
| A - Head tube length | 165 mm |
| B - Seat tube length | 710 mm |
| C - Wheelbase | 993 mm |
| D - Top tube length | 564 mm |
| E - Stack | 571 mm |
| F - Stack+ | 622 mm |
| G - Reach | 391 mm |
| H - Reach+ | 582 mm |
| I - Seat angle | 73.3 ° |
| J - Head angle | 73.2 ° |
| K - STR | 1.46 |
| L - STR+ | 1.07 |
Area of application
Tour
100
Wettkampf
Terrain
off-road
99
road
0
33
66
100
Sitting position
upright
75
stretched
0
33
66
100
Tests & Reviews
Equipment
| Rear brakes | SRAM Red |
| Front brakes | SRAM Red |
| Brakes | SRAM Red |
| Front brake disc | 160 |
| Rear brake disc | 140 |
| Drivetrain | SRAM Red AXS |
| Shift levers | SRAM Red AXS |
| Fork | Giant Propel Advanced |
| Crankset | SRAM Red AXS Powertap |
| Sprocket | SRAM Red |
| Drive type | Chain |
| Handlebar | Giant Contact SLR Aero |
| Stem | Giant Contact SLR Aero |
| Saddle | Giant Cadex SMC Carbon |
| Seatpost | Giant Propel seat dome |
| Wheelset | Giant Cadex Max 50 |
| Wheel size | 28"/622mm |
| Front tire | Giant Cadex Aero TR Hookless 28-622 |
| Rear tire | Giant Cadex Aero TR Hookless 28-622 |
