Canyon Endurace SLX Ultegra Di2
Model: Endurace SLX Ultegra Di2
Model year: 2026
Category: Rennrad
Frame material: Carbon
Weight: 8.02 kg
Wheel size: 28"/622mm
Test result
| Property | Weighting | Grade |
|---|---|---|
| Lab | 75% | 2,3 |
| Complete bike weight | 25% | 3,0 |
| Rear comfort | 20% | 2,0 |
| Front comfort | 10% | 2,0 |
| Acceleration | 10% | 2,3 |
| Ride stability | 10% | 1,7 |
| Equipment | 25% | 1,1 |
| Brakes | 5% | 1,0 |
| Shifting | 5% | 1,0 |
| Tires | 5% | 1,0 |
| Paint | 5% | 1,0 |
| Maintenance / Adjustments | 5% | 1,5 |
| Final grade | 2,0 |
Strengths and weaknesses
| Complete bike weight | 8020 g |
| Ride stability | 8,10 N/mm |
| Rear comfort | 129,02 N/mm |
| Front comfort | 79,56 N/mm |
| Sprint / BB stiffness | 52,82 N/mm |
Geometry - measurements overview
H
G
F
D
B
E
C
I
J
A
K
L
M
| A - Head tube length | 160 mm |
| B - Seat tube length | 520 mm |
| C - Wheelbase | 1009 mm |
| D - Top tube length | 571 mm |
| E - Stack | 591 mm |
| F - Stack+ | 653 mm |
| G - Reach | 384 mm |
| H - Reach+ | 546 mm |
| I - Seat angle | 73.2 ° |
| J - Head angle | 72.6 ° |
| K - STR | 1.54 |
| L - STR+ | 1.20 |
Tests & Reviews
Equipment
| Rear brakes | Shimano Ultegra |
| Front brakes | Shimano Ultegra |
| Brakes | Shimano Ultegra |
| Front brake disc | 160 |
| Rear brake disc | 160 |
| Drivetrain | Shimano Ultegra Di2 |
| Shift levers | Shimano Ultegra Di2 |
| Drivetrain type | Derailleur |
| Front derailleur | Shimano Ultegra Di2 |
| Number of gears | 24 |
| Fork | Canyon Endurace Carbon |
| Crankset | Shimano Ultegra |
| Sprocket | Shimano Ultegra |
| Handlebar | Canyon Core Race Bar |
| Saddle | Fizik Aliante |
| Seatpost | Canyon SP 0093 |
| Wheelset | DT-Swiss ERC 1600 |
| Wheel size | 28"/622mm |
| Front tire | Schwalbe Pro One TLE 32-622 |
| Rear tire | Schwalbe Pro One TLE 32-622 |
