Canyon Endurace CFR
Model: Endurace CFR
Model year: 2026
Category: Rennrad
Frame material: Carbon
Weight: 7.52 kg
Wheel size: 28"/622mm
Test result
| Property | Weighting | Grade |
|---|---|---|
| Lab | 75% | 2,1 |
| Complete bike weight | 25% | 2,7 |
| Rear comfort | 20% | 2,3 |
| Front comfort | 10% | 2,0 |
| Acceleration | 10% | 1,0 |
| Ride stability | 10% | 1,3 |
| Equipment | 25% | 1,2 |
| Brakes | 5% | 1,0 |
| Shifting | 5% | 1,0 |
| Tires | 5% | 1,0 |
| Paint | 5% | 1,0 |
| Maintenance / Adjustments | 5% | 2,0 |
| Final grade | 1,9 |
Strengths and weaknesses
| Complete bike weight | 7525 g |
| Ride stability | 8,57 N/mm |
| Rear comfort | 152,99 N/mm |
| Front comfort | 75,52 N/mm |
| Sprint / BB stiffness | 72,48 N/mm |
Geometry - measurements overview
H
G
F
D
B
E
I
J
C
A
K
L
M
| A - Head tube length | 143 mm |
| B - Seat tube length | 520 mm |
| C - Wheelbase | 992 mm |
| D - Top tube length | 569 mm |
| E - Stack | 565 mm |
| F - Stack+ | 629 mm |
| G - Reach | 389 mm |
| H - Reach+ | 584 mm |
| I - Seat angle | 73.5 ° |
| J - Head angle | 73.9 ° |
| K - STR | 1.45 |
| L - STR+ | 1.08 |
Area of application
Tour
75
Wettkampf
Terrain
off-road
75
road
0
33
66
100
Sitting position
upright
75
stretched
0
33
66
100
Tests & Reviews
Equipment
| Rear brakes | Shimano Dura Ace |
| Front brakes | Shimano Dura Ace |
| Brakes | Shimano Dura Ace |
| Front brake disc | 160 |
| Rear brake disc | 160 |
| Drivetrain | Shimano Dura Ace Di2 |
| Shift levers | Shimano Dura Ace Di2 |
| Drivetrain type | Derailleur |
| Front derailleur | Shimano Dura Ace Di2 |
| Number of gears | 24 |
| Fork | Canyon Endurace |
| Crankset | Shimano Dura Ace |
| Sprocket | Shimano Dura Ace |
| Drive type | Chain |
| Handlebar | Canyon Core Base Bar CP0048 |
| Stem | Canyon Core Base Bar CP0048 |
| Saddle | Selle Italia SLR Superflow |
| Seatpost | Canyon SP 105 |
| Wheelset | DT-Swiss ARC 1100 Dicut |
| Wheel size | 28"/622mm |
| Front tire | Pirelli P Zero Race RS TLR 700 x 35c |
| Rear tire | Pirelli P Zero Race RS TLR 700 x 35c |
